Water Treatment Sidestream Treatment Pump Station Model

Vinci Digital Worksite™ | Sidestream Treatment Pump Station.

Vinci Digital Worksite™ model of a peak flow pump station for a waste water treatment facility at A9A09. Model includes footings, foundation walls, reinforced concrete slabs, walls, and weirs, formwork, structural steel and bar joists, metal decking, roof and wall insulation, face brick, fenestration, electrical lights and panels, and connections to yard piping.

Click for more: wet infrastructure project examples or modeled facilities, project schedule; preliminary facility scheduling.
