R7B54 | Vinci™ Vignette | Road Widening | Existing Conditions

Every audience organization, however brilliant, sometimes misses details of their own worksite. The audience in this case suggested use of a road for all construction access and hauling. The road proves to be minimally narrow. This image helped Vinci’s client identify this constraint, then illustrate other issues on Basin 2.
