R7B54 | Vinci™ Vignette | Hoisting Studies | Application: Typical Solution

This Vinci™ Vignette image illustrates the trouble with the typical solution to the audience organization’s project. The Runway Protection Zone would be violated. The offending mast of the tower crane is visible at the top of the image near the center. « Previous Vignette | « Previous in Sequence | Next in Sequence » | Orientation Images »
