Water Treatment Plant Concrete Facility Phasing Construction Proposal Diagram

Vinci Construction Proposal Diagram | Late Facility Phasing.

A good general approach in assembling proposal imagery is to accentuate commencement and completion of phases. This approach shows the audience the state of the worksite at those points and demonstrate why the phase is distinct from other phases you’ve broken out. In this plate we see an early phase more or less complete beyond, and the latter phase in progress in the foreground. Your narrative will convey the logic of separating these two phases. Vinci LLC has produced high-resolution plates for printed proposals since 2004. These images can seamlessly flow directly into your team’s proposal document to illustrate key points in your narrative. Interview imagery can naturally follow on after proposal work is complete.

Click for more: plantwide schedule; excavation at channels, demolition, worksite model detail, facility highlight, cutaway. Go behind the scenes to see terrain or context modeling, preliminary facility scheduling.
